聚氯乙烯绝缘护套控制电缆
型号 | 名 称 | 主要使用范围 |
KVV | 铜芯聚氯乙烯绝缘氯乙烯护套控制电缆 | 敷设在室内、电缆沟、管道固定场合 |
KVVP | 铜芯聚氯乙烯绝缘氯乙烯护套编织屏蔽控制电缆 | 敷设在室内、电缆沟、管道等要求屏蔽的固定场合 |
KVVP2 | 铜芯聚氯乙烯绝缘氯乙烯护套编织屏蔽控制电缆 | 同 上 |
KVV22 | 铜芯聚氯乙烯绝缘氯乙烯护套钢带铠装控制电缆 | 敷设在室内、电缆沟、管道、直埋等能承受较大机械外力固定场合 |
KVV32 | 铜芯聚氯乙烯绝缘氯乙烯护套编织屏蔽控制软电缆 | 敷设在室内、电缆沟、管道、竖井等能承受较大机械外力固定场合 |
KVVR | 铜芯聚氯乙烯绝缘氯乙烯护套钢带铠装控制电缆 | 敷设在室内移动要求柔软等场合 |
| ZR-KVVRP | 铜芯聚氯乙烯绝缘氯乙烯护套钢带铠装控制电缆 | 室内移动要求柔软屏蔽等场合 |
| ZR-KVV | 铜芯聚氯乙烯绝缘氯乙烯护套编织屏蔽控制软电缆 | 敷设有阻燃要求的室内，电缆沟，管道等固定场合 |
| ZR-KVVP2 | 铜芯聚氯乙烯绝缘氯乙烯护套铜带屏蔽阻燃控制电缆 | 敷设有阻燃要求的室内，电缆沟，管道等固定场合 |
| ZR-KVV2 | 铜芯聚氯乙烯绝缘氯乙烯护套铜带铠装阻燃控制电缆 | 敷设有阻燃要求的室内，电缆沟，管道直埋等能承受较大机构外力固定场合 |
| ZR-KVVR | 铜芯聚氯乙烯绝缘氯乙烯护套阻燃控制电缆 | 敷设有阻燃要求的室内可移动柔软等场合 |
二、电缆结构图
 |  | |
|
1、导体 2、绝缘层 3、包带 |
4、垫层 5、铜带屏蔽 6、外护层 |
三、电缆结构材料及性能
KVV型ZR-KVV型450/750V铜芯聚氯乙烯绝缘聚氯乙烯护套控制电缆
|
芯数×标称 截面(mm2) | 绝缘厚度 | 护套标称厚度 | 平均外径mm |
70℃最小绝缘 电阻(MΩ．Km) |
20℃最大绝缘 电阻(MΩ．Km) | 近似重量 | |
| 下限 | 上限 | ||||||
|
2*0.75 2*1.0 2*1.5 2*2.5 2 4 2*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.2 1.2 1.2 1.2 1.2 |
6.4 6.8 7.6 8.6 9.6 10.5 |
8.0 8.4 9.4 10.5 11.5 12.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
59 67 86 120 167 220 |
|
3*0.75 3*1.0 3*1.5 3*2.5 3*4 3*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.2 1.2 1.2 1.2 1.5 |
6.8 7.0 8.0 9.2 10.0 11.5 |
8.4 8.8 9.8 11.0 12.5 14.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
71 82 108 154 210 310 |
|
4*0.75 4*1.0 4*1.5 4*2.5 4*4 4*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.2 1.2 1.2 1.5 1.5 |
7.2 7.6 8.6 10.0 11.5 12.5 |
9.0 9.4 10.5 12.0 14.0 15.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
846 100 132 193 315 413 |
|
5*0.75 5*1.0 5*1.5 5*2.5 5*4 5*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.2 1.2 1.5 1.5 1.5 |
7.8 8.2 9.4 11.5 12.5 14.0 |
9.6 10.0 11.5 14.0 15.0 16.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
99 116 154 243 383 505 |
|
7*0.75 7*1.0 7*1.5 7*2.5 7*4 7*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.2 1.2 1.5 1.5 1.5 |
8.4 9.0 10.0 12.5 13.5 15.0 |
10.5 11.0 12.5 15.0 16.5 18.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
123 146 196 211 473 652 |
|
8*0.75 8*1.0 8*1.5 8*2.5 8*4 8*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.2 1.5 1.5 1.5 1.7 |
9.4 10.0 12.0 14.0 15.5 17.5 |
11.5 12.0 14.5 16.5 18.0 20.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
142 1168 243 360 545 748 |
|
10*0.75 10*1.0 10*1.5 10*2.5 10*4 10*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.2 1.5 1.5 1.5 1.7 1.7 |
10.5 11.5 13.5 15.5 18.0 19.5 |
12.5 14.0 16.0 18.5 20.5 22.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
187 221 296 440 721 956 |
|
12*0.75 12*1.0 12*1.5 12*2.5 12*4 12*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.5 1.5 1.5 1.5 1.7 1.7 |
11.5 12.0 14.0 16.0 18.5 20.5 |
13.5 14.5 16.5 19.0 21.5 23.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
211 250 338 507 825 1026 |
|
14*0.75 14*1.0 14*1.5 14*2.5 14*4 14*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
1.5 1.5 1.5 1.5 1.7 1.7 |
12.0 12.5 14.5 17.0 19.5 21.5 |
14.5 15.0 17.0 19.5 22.5 24.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
238 328 384 579 959 1246 |
|
16*0.75 16*1.0 16*1.5 16*2.5 |
0.6 0.6 0.7 0.8 |
1.5 1.5 1.5 1.7 |
12.5 13.0 15.0 18.0 |
15.0 15.5 18.0 21.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
2268 315 427 664 |
|
19*0.75 19*1.0 19*1.5 19*2.5 |
0.6 0.6 0.7 0.8 |
1.5 1.5 1.5 1.7 |
13.0 14.0 16.0 19.0 |
15.5 16.5 19.0 22.0 |
0.012 0.011 0.011 0.01 |
24.5 18.1 12.1 7.41 |
299 359 490 765 |
|
24*0.75 24*1.0 24*1.5 24*2.5 |
0.6 0.6 0.7 0.8 |
1.5 1.5 1.7 1.7 |
15.0 16.0 19.0 22.5 |
18.0 19.0 22.0 25.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
373 447 632 961 |
|
27*0.75 27*1.0 27*1.5 27 2.5 |
0.6 0.6 0.7 0.8 |
1.5 1.5 1.7 1.7 |
15.5 16.5 19.5 23.0 |
18.0 19.0 22.5 26.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
407 491 694 1061 |
|
30*0.75 30*1.0 30*1.5 30*2.5 |
0.6 0.6 0.7 0.8 |
1.5 1.7 1.7 1.7 |
16.0 17.5 20.0 24.0 |
19.0 20.5 23.0 27.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
445 554 761 1167 |
|
37*0.75 37*1.0 37*1.5 37*2.5 |
0.6 0.6 0.7 0.8 |
1.7 1.7 1.7 1.7 |
17.5 18.5 21.5 25.5 |
20.5 21.5 25.0 29.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
544 658 908 1401 |
|
44*0.75 44*1.0 44*1.5 44 2.5 |
0.6 0.6 0.7 0.8 |
1.7 1.7 1.7 2.0 |
19.5 21.0 24.5 29.5 |
23.0 24.0 28.0 33.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
642 777 1074 1702 |
|
52*0.75 52*1.0 52*1.5 52*2.5 |
0.6 0.6 0.7 0.8 |
1.7 1.7 1.7 2.0 |
20.0 22.0 25.5 31.0 |
23.0 25.0 29.0 35.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
737 896 1243 1973 |
|
61*0.75 61*1.0 61*1.5 61*2.5 |
0.6 0.6 0.7 0.8 |
1.7 1.7 2.0 2.2 |
22.0 23.0 27.5 33.0 |
25.0 26.5 31.5 37.5 |
0.012 0.011 0.011 0.0100 |
24.5 18.1 12.1 7.41 |
843 1027 1468 2306 |
|
芯数×标称 截面(mm2) | 绝缘厚度 | 钢带厚度 | 平均外径mm |
70℃最小绝缘 电阻(MΩ．Km) |
20℃最大绝缘 电阻(MΩ．Km) | 近似重量 | ||
| 下限 | 护套厚度 | 上限 | ||||||
|
4*0.75 4*1.0 4*1.5 4*2.5 4*4 4*6 4*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
8.0 8.4 9.4 11.0 12.5 13.5 17.5 |
1.2 1.2 1.5 1.5 1.5 1.7 |
10.0 10.5 11.5 14.0 15.0 16.0 21.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
144 153 190 276 367 467 728 |
|
5*0.75 5*1.0 5*1.5 5*2.5 5*4 5*6 5*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
8.6 9.0 10.0 12.0 13.5 14.5 19.0 |
1.2 1.2 1.5 1.5 1.5 1.7 |
11.0 11.0 12.5 15.0 16.0 17.5 23.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
153 173 226 325 437 576 924 |
|
7*0.75 7*1.0 7*1.5 7*2.5 7*4 7*6 7*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
9.2 9.6 11.5 13.0 14.5 16.0 20.5 |
1.2 1.2 1.5 1.5 1.5 1.7 |
11.5 12.0 14.0 16.0 17.5 19.0 25.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
178 209 239 398 528 717 1145 |
|
8*0.75 8*1.0 8*1.5 8*2.5 8*4 8*6 8*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
10.0 11.0 12.5 14.5 16.0 18.0 23.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 |
12.5 13.5 15.5 17.5 19.0 21.0 28.0 | 0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
206 230 312 486 589 790 1236 |
|
10*0.75 10*1.0 10*1.5 10*2.5 10*4 10*6 10*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
11.5 12.5 14.0 16.5 18.5 20.5 26.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 | 14.5 15.0 17.0 19.5 21.5 23.5 31.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
214 300 367 572 787 992 1590 |
|
12*0.75 12*1.0 12*1.5 12*2.5 12*4 12*6 |
0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
12.0 12.5 14.5 17.0 19.0 21.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 | 14.5 15.5 17.5 20.5 22.5 24.5 | 0.012 0.011 0.011 0.010 0.0085 0.0070 |
280 315 423 654 887 1198 | |
|
14*0.75 14*1.0 14*1.5 14*2.5 14*4 14*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
12.5 13.5 15.0 18.0 20.0 22.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 | 15.5 16.0 18.0 21.0 23.5 25.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 | 312 398 492 721 973 1203 |
|
16*0.75 16*1.0 16*1.5 16*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
13.0 14.0 16.0 19.0 |
1.5 1.5 1.5 1.7 | 16.0 16.5 19.0 22.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
340 389 489 789 |
|
19*0.75 19*1.0 19*1.5 19*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
14.0 14.5 16.5 20.0 |
1.5 1.5 1.7 1.7 |
16.5 17.5 20.0 23.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
386 413 612 986 |
|
24*0.75 24*1.0 24*1.5 24*2.5 |
0.6 0.6 0.7 0.8 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
16.0 17.0 20.0 23.0 |
1.5 1.7 1.7 1.7 |
19.0 20.5 23.0 26.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
476 580 792 1179 |
|
27*0.75 27*1.0 27*1.5 27*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
16.0 17.5 20.0 23.5 |
1.7 1.7 1.7 1.7 | 19.0 20.5 23.5 27.0 |
0.012 0.011 0.011 0.010 |
224.5 18.1 12.1 7.414.5 18.1 12.1 7.41 |
503 612 886 1286 |
|
30*0.75 30*1.0 30*1.5 30*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
17.0 18.0 21.0 24.5 |
1.7 1.7 1.7 1.7 |
20.0 21.5 24.0 28.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
600 725 891 1384 |
|
37*0.75 37*1.0 37*1.5 37*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
18.5 19.5 22.5 26.5 |
1.7 1.7 1.7 2.0 |
21.5 22.5 26.0 30.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
887 1105 1681 |
|
44*0.75 44*1.0 44*1.5 44*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
20.5 21.5 25.0 30.0 |
1.7 1.7 1.7 2.0 |
24.0 25.0 29.0 34.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
809 987 1315 2018 |
|
48*0.75 48*1.0 48*1.5 48*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
21.0. 22.0 25.5 30.5 |
1.7 1.7 1.7 2.0 |
24.0 25.5 29.5 35.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
2018 910 1028 1307 2097 |
|
52*0.75 52*1.0 52*1.5 52*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
21.5 22.5 26.0 31.5 |
1.7 1.7 1.7 2.0 |
24.5 26.0 20.0 36.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
935 1113 1493 2298 |
|
61*0.75 61*1.0 61*1.5 61*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
22.5 24.0 28.5 34.0 |
1.7 1.7 1.7 2.0 |
26.0 27.0 32.5 38.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1025 1250 1745 2599 |
|
芯数×标称 截面(mm2) | 绝缘厚度 | 钢带厚度 | 平均外径mm |
70℃最小绝缘 电阻(MΩ．Km) |
20℃最大绝缘 电阻(MΩ．Km) | 近似重量 | ||
| 下限 | 护套厚度 | 上限 | ||||||
|
4*0.75 4*1.0 4*1.5 4*2.5 4*4 4*6 4*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
8.0 8.4 9.4 11.0 12.5 13.5 17.5 |
1.2 1.2 1.5 1.5 1.5 1.7 |
10.0 10.5 11.5 14.0 15.0 16.0 21.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
144 153 190 276 367 467 728 |
|
5 0.75 5 1.0 5 1.5 5 2.5 5 4 5 6 5 10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
8.6 9.0 10.0 12.0 13.5 14.5 19.0 |
1.2 1.2 1.5 1.5 1.5 1.7 |
11.0 11.0 12.5 15.0 16.0 17.5 23.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
153 173 226 325 437 576 924 |
|
7*0.75 7*1.0 7*1.5 7*2.5 7*4 7*6 7*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
9.2 9.6 11.5 13.0 14.5 16.0 20.5 |
1.2 1.2 1.5 1.5 1.5 1.7 |
11.5 12.0 14.0 16.0 17.5 19.0 25.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
178 209 239 398 528 717 1145 |
|
8*0.75 8*1.0 8*1.5 8*2.5 8*4 8*6 8*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
10.0 11.0 12.5 14.5 16.0 18.0 23.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 |
12.5 13.5 15.5 17.5 19.0 21.0 28.0 | 0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
206 230 312 486 589 790 1236 |
|
10*0.75 10*1.0 10*1.5 10*2.5 10*4 10*6 10*10 |
1.0 0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
11.5 12.5 14.0 16.5 18.5 20.5 26.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 | 14.5 15.0 17.0 19.5 21.5 23.5 31.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
214 300 367 572 787 992 1590 |
|
12*0.75 12*1.0 12*1.5 12*2.5 12*4 12*6 |
0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
12.0 12.5 14.5 17.0 19.0 21.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 | 14.5 15.5 17.5 20.5 22.5 24.5 | 0.012 0.011 0.011 0.010 0.0085 0.0070 |
280 315 423 654 887 1198 | |
|
14*0.75 14*1.0 14*1.5 14*2.5 14*4 14*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
12.5 13.5 15.0 18.0 20.0 22.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 | 15.5 16.0 18.0 21.0 23.5 25.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 | 312 398 492 721 973 1203 |
|
16*0.75 16*1.0 16*1.5 16*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
13.0 14.0 16.0 19.0 |
1.5 1.5 1.5 1.7 | 16.0 16.5 19.0 22.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
340 389 489 789 |
|
19*0.75 19*1.0 19*1.5 19*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
14.0 14.5 16.5 20.0 |
1.5 1.5 1.7 1.7 |
16.5 17.5 20.0 23.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
386 413 612 986 |
|
24*0.75 24*1.0 24*1.5 24*2.5 |
0.6 0.6 0.7 0.8 |
0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
16.0 17.0 20.0 23.0 |
1.5 1.7 1.7 1.7 |
19.0 20.5 23.0 26.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
476 580 792 1179 |
|
27*0.75 27*1.0 27*1.5 27*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
16.0 17.5 20.0 23.5 |
1.7 1.7 1.7 1.7 | 19.0 20.5 23.5 27.0 |
0.012 0.011 0.011 0.010 |
224.5 18.1 12.1 7.414.5 18.1 12.1 7.41 |
503 612 886 1286 |
|
30*0.75 30*1.0 30*1.5 30*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
17.0 18.0 21.0 24.5 |
1.7 1.7 1.7 1.7 |
20.0 21.5 24.0 28.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
600 725 891 1384 |
|
37*0.75 37*1.0 37*1.5 37*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
18.5 19.5 22.5 26.5 |
1.7 1.7 1.7 2.0 |
21.5 22.5 26.0 30.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
887 1105 1681 |
|
44*0.75 44*1.0 44*1.5 44*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
20.5 21.5 25.0 30.0 |
1.7 1.7 1.7 2.0 |
24.0 25.0 29.0 34.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
809 987 1315 2018 |
|
48*0.75 48*1.0 48*1.5 48*2.5 | 0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
21.0. 22.0 25.5 30.5 |
1.7 1.7 1.7 2.0 |
24.0 25.5 29.5 35.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
2018 910 1028 1307 2097 |
|
52*0.75 52*1.0 52*1.5 52*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
21.5 22.5 26.0 31.5 |
1.7 1.7 1.7 2.0 |
24.5 26.0 20.0 36.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
935 1113 1493 2298 |
|
61*0.75 61*1.0 61*1.5 61*2.5 |
0.6 0.6 0.7 0.8 | 0.05-0.15 0.05-0.15 0.05-0.15 0.05-0.15 |
22.5 24.0 28.5 34.0 |
1.7 1.7 1.7 2.0 |
26.0 27.0 32.5 38.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1025 1250 1745 2599 |
|
芯数×标称 截面(mm2) | 绝缘厚度 | 钢带厚度 | 平均外径mm |
70℃最小绝缘 电阻(MΩ．Km) |
20℃最大绝缘 电阻(MΩ．Km) | 近似重量 | ||
| 下限 | 护套厚度 | 上限 | ||||||
|
4*2.5 4*4 4*6 4*10 |
0.8 0.8 0.8 1.0 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
13.0 14.0 15.5 19.0 |
1.5 1.5 1.5 1.7 |
17.0 18.5 19.0 25.0 |
0.010 0.0085 0.0070 0.0065 |
7.41 4.61 3.08 1.83 |
505 619 947 |
|
5*2.5 5*4 5*6 5*10 |
0.8 0.8 0.8 1.0 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
14.0 15.0 17.0 20.5 |
1.5 1.5 1.5 1.7 |
18.0 19.5 21.5 26.5 |
0.010 0.0085 0.0070 0.0065 |
7.41 4.61 3.08 1.83 |
586 737 1125 |
|
7*0.75 7*1.0 7*1.5 7*á2.5 7*4 7*6 7*10 |
0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
11.5 12.0 13.5 15.0 16.5 18.0 22.5 |
1.5 1.5 1.5 1.5 1.5 1.7 1.7 |
15.5 16.0 17.5 19.0 20.5 22.5 28.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
317 354 425 554 701 900 1397 |
|
8*0.75 8*1.0 8*1.5 8*2.5 8*4 8*6 8*10 |
0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
12.5 13.0 14.5 16.5 18.5 20.0 25.0 |
1.5 1.5 1.5 1.5 1.7 1.7 1.7 |
16.5 17.0 18.5 21.0 23.0 24.5 31.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
344 378 467 614 789 989 1540 |
|
10*0.75 10*1.0 10*1.5 10*2.5 10*4 10*6 10*10 |
0.6 0.6 0.7 0.8 0.8 0.8 1.0 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
13.5 14.5 16.0 18.5 20.5 22.5 28.5 |
1.5 1.5 1.5 1.7 1.7 1.7 2.0 |
18.0 18.5 20.5 23.0 25.0 27.0 35.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 0.0065 |
24.5 18.1 12.1 7.41 4.61 3.08 1.83 |
449 558 753 956 1203 |
|
12*0.75 12*1.0 12*1.5 12*2.5 12*4 12*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
14.0 14.5 16.5 19.0 21.0 23.0 |
1.5 1.5 1.5 1.7 1.7 1.7 |
18.0 19.0 20.5 23.5 25.5 28.5 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
485 609 829 1061 |
|
14*0.75 14*1.0 14*1.5 14*2.5 14*4 14*6 |
0.6 0.6 0.7 0.8 0.8 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
14.5 15.0 17.5 20.0 22.0 24.0 |
1.5 1.5 1.7 1.7 1.7 1.7 |
18.5 19.5 22.0 24.5 26.5 29.0 |
0.012 0.011 0.011 0.010 0.0085 0.0070 |
24.5 18.1 12.1 7.41 4.61 3.08 |
412 530 684 913 1171 1508 |
|
16*0.75 16*1.0 16*1.5 16*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
15.0 16.0 18.0 21.0 |
1.5 1.5 1.7 1.7 |
19.5 20.0 22.5 25.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
576 745 1005 1350 |
|
19*0.75 19*1.0 19*1.5 19*2. |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
15.5 17.0 19.0 22.0 |
1.5 1.7 1.7 1.7 |
20.0 21.5 23.5 26.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
646 824 1199 1480 |
|
24*0.75 24*1.0 24*1.5 24*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
18.0 19.0 21.5 25.0 |
1.7 1.7 1.7 1.7 |
22.5 23.5 26.5 30.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
776 1001 1376 1590 |
|
27*0.75 27*1.0 27*1.5 27*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
18.5 19.5 22.5 25.5 |
1.7 1.7 1.7 1.7 |
23.0 24.0 27.0 30.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 | 821 1063 1480 1730 |
|
30*0.75 30*1.0 30*1.5 30*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
19.0 20.0 230 26.5 |
1.7 1.7 1.7 1.7 |
23.5 24.5 27.5 31.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 | 883 1550 1808 2050 |
|
37*0.75 37*1.0 37*1.5 37*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
20.5 21.5 24.5 30.0 |
1.7 1.7 1.7 2.0 |
25.0 26.0 29.0 35.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1013 1331 2139 2370 |
|
44*0.75 44*1.0 44*1.5 44*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) |
22.5 23.5 27.5 33.5 | 1.7 1.7 2.0 2.0 |
27.0 28.5 33.0 39.0 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1120 1584 2320 2532 |
|
48*0.75 48*1.0 48*1.5 48*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.2(0.3) 2 á0.5 |
22.5 24.0 29.0 34.0 |
1.7 1.7. 2.0 2.2 |
27.5 29.0 24.0 39.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1160 1630 2530 2662 |
|
52*0.75 52*1.0 52*1.5 52*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.5 2*0.5 |
23.0 24.5 30.0 35.0 | 1.7 1.7 2.0 2.2 | 28.0 29.5 35.0 40.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1210 1750 2580 2710 |
|
61*0.75 61*1.0 61*1.5 61*2.5 |
0.6 0.6 0.7 0.8 |
2*0.2(0.3) 2*0.2(0.3) 2*0.5 2*0.5 |
24.5 26.0 31.5 37.0 |
1.7 1.7 2.0 2.2 |
29.5 31.0 36.5 42.5 |
0.012 0.011 0.011 0.010 |
24.5 18.1 12.1 7.41 |
1280 1930 2770 3175 |
|
芯数×标称 截面(mm2) | 绝缘厚度 | 护套标称厚度 | 平均外径mm |
70℃最小绝缘 电阻(MΩ．Km) |
20℃最大绝缘 电阻(MΩ．Km) | |
| 下限 | 上限 | |||||
|
*0.5 4*0.75 4*1.0 4*1.5 4*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.2 1.2 1.2 1.2 |
7.2 7.6 8.0 9.0 10.5 |
9.0 9.4 10.0 11.5 13.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
5*0.5 5*0.75 5*1.0 5*1.5 5*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.2 1.2 1.2 1.5 |
7.8 8.4 8.8 9.8 12.0 |
9.0 10.5 11.0 12.0 14.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
7*0.5 7*0.75 7*1.0 7*1.5 7*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.2 1.2 1.2 1.5 |
8.4 9.0 9.6 10.5 13.0 |
10.5 11.0 11.5 13.0 16.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
8*0.5 8*0.75 8*1.0 8*1.5 8*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.2 1.2 1.5 1.5 |
9.4 10.0 10.5 12.5 15.0 |
11.5 12.0 13.0 15.0 17.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
10*0.5 10*0.75 10*1.0 10*1.5 10*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.2 1.5 1.5 1.5 |
10.5 11.0 12.5 14.0 16.5 |
13.5 15.0 16.0 18.0 21.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
12*0.5 12*0.75 12*1.0 12*1.5 12*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.5 1.5 1.5 1.5 |
10.5 12.0 12.5 14.5 17.5 |
13.5 15.0 16.0 18.0 21.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
14*0.5 14*0.75 14*1.0 14*1.5 14*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.2 1.5 1.5 1.5 1.5 |
11.0 12.5 13.5 15.0 18.0 |
13.5 15.0 16.0 18.0 21.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
16*0.5 16*0.75 16*1.0 16*1.5 16*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.5 1.5 1.5 1.5 1.7 |
12.5 13.5 14.0 16.0 19.5 |
15.0 16.0 17.0 19.0 23.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
19*0.5 19*0.75 19*1.0 19*1.5 19*2.5 | 0.6 0.6 0.6 0.7 0.8 |
1.5 1.5 1.5 1.5 1.7 |
13.0 14.0 15.0 16.5 20.5 |
15.5 16.5 17.5 20.0 24.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
24*0.5 24*0.75 24*1.0 24*1.5 24*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.5 1.5 1.5 1.7 1.7 |
15.0 16.0 17.0 20.0 24.0 |
18.0 19.0 20.0 23.5 27.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
27*0.5 27*0.75 27*1.0 27*1.5 27*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.5 1.5 1.5 1.7 1.7 |
15.0 16.5 17.5 20.5 24.5 |
18.0 19.5 20.5 24.0 28.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
30*0.5 30*0.75 30*1.0 30*1.5 30*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.5 1.5 1.7 1.7 1.7 |
16.0 17.0 18.5 21.0 25.5 |
18.5 20.0 21.5 25.0 29.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
37*0.5 37*0.75 37*1.0 37*1.5 37*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.5 1.7 1.7 1.7 1.7 |
17.0 19.0 20.0 22.5 27.5 |
20.0 21.5 23.5 27.0 31.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
44*0.5 44*0.75 44*1.0 44*1.5 44*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.7 1.7 1.7 1.7 2.0 |
19.5 21.0 22.5 25.5 32.0 |
22.5 24.5 26.0 30.0 36.0 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
48*0.5 48*0.75 48*1.0 48*1.5 48*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.7 1.7 1.7 1.7 2.0 |
20.0 21.5 23.0 26.0 32.5 |
23.0 25.0 26.5 30.5 36.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
|
52*0.5 52*0.75 52*1.0 52*1.5 52*2.5 |
0.6 0.6 0.6 0.7 0.8v |
1.7 1.7 1.7 1.7 2.0 |
20.5 22.0 23.5 26.5 33.0 |
23.5 25.5 27.0 31.0 37.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
61*0.5 61*0.75 61*1.0 61*1.5 61*2.5 |
0.6 0.6 0.6 0.7 0.8 |
1.7 1.7 1.7 2.0 2.2 | 21.5 23.5 25.0 29.0 35.5 |
25.0 27.0 28.5 33.5 40.5 |
0.013 0.011 0.010 0.010 0.009 |
39.0 26.0 19.5 13.3 7.98 |
地 址：浙江省乐清市经济开发区经五路268号
全国统一客服热线：400-0700-118 电 话：0577-62056161
阿里巴巴网址：zghongqidianlan.1688.com
浙ICP备19034639号-1@2013-2018 © 中国·红旗集团 版权所有
@2013-2018 © 中国·红旗集团 版权所有
